GEOMAGIC DESIGN X

REVERSE ENGINEERING SOFTWARE

The fastest path from scan to CAD.

Reverse engineer physical parts into digital parametric CAD models with a reverse engineering software that combines history-based CAD with 3D scan data processing.

Screen Shot 2021-06-27 at 9.55.34 PM.png

Why Geomagic Design X?

  • Speed: Improve your product development, accelerate time to market and achieve longer product life cycles.

  • Flexibility. Work seamlessly with any CAD software and create the right model for every project with complete toolsets for solids, surfaces, and meshes.

  • Reliability: The only software that combines scan processing, CAD and real-time feedback to produce highly reliable results for your complex designs.

  • Simplicity: It works just like your CAD software, you will learn to use it on the fly.

What is Geomagic Design X?



Geomagic® Design X™ creates CAD models from 3D scans faster, more accurately and reliably than any other reverse-engineering software, enabling you to create new business value out of existing products.

  • Processes large scan data sets with millions of points faster than any other reverse-engineering software.

  • Creates complex hybrid 3D models for solid, surface, and mesh.

  • Connects directly to your CAD environment and creates native files to accurately represent a scanned object.

  • Rapidly creates solids or surfaces just like in CAD.

  • Transfers 3D parametric models with full design history directly to any popular CAD software.

What Can You Do with Geomagic Design X?

Geomagic Design X converts 3D scan data into high-quality, feature-based CAD models. The software combines automatic and guided solid model extraction in a unique way while being incredibly accurate. On top of this it offers you exact surface fitting to organic 3D scans; mesh editing; and point-cloud processing.

  • Expand your design capabilities.

  • Enhance your CAD environment.

  • Accelerate your time to market.

  • Leverage existing assets.

  • Reduce costs.

  • Manage the impossible.

Scan virtually anything and create producible designs.

  • Rebuild CAD data for broken tools and molds.

  • Recreate lost CAD data for parts and molds.

  • Design custom products.

  • Convert physical parts into CAD for new product designs.

  • Make existing parts fit with new parts.



Geomagic Design X seamlessly supports all major scanners and portable CRMs. Read our 3D scanning guide to find out what types of scanners work best for you.

Use Geomagic Design X with Geomagic Control X™ and Geomagic Wrap® for an end-to-end, scan-based design and inspection package.

Download Brochure
